Tubesheet Flange- High-Performance Industrial Connection Solution

Shanxi HongKai Forging Co., Ltd. specializes in manufacturing premium Tubesheet Flange products" target="_blank">products with integrated production capabilities spanning forging, heat treatment, machining, and comprehensive quality testing. Our enterprise-level solutions feature specifications ranging from DN15 to DN4000, pressure ratings up to Class 2500, and compliance with multiple international standards including ASME B16.5, EN1092-1, and DIN. With three department workplaces and free import-export rights, we provide prevalent channeling association arrangements for requesting mechanical applications worldwide.

What is Tubesheet Flange

A Tubesheet Flange is a thick circular plate or forged flange component with multiple precision-drilled tube holes. It is mainly used to support, locate, and seal tubes in shell-and-tube heat exchangers.

Unlike standard pipe flanges, tubesheet flanges require accurate tube hole layout, strict flatness control, precise sealing surface machining, and reliable material performance. The tube holes are usually arranged according to triangular pitch, square pitch, or customized tube layout.

Tubesheet flanges can be supplied as forged tubesheets, clad tubesheets, drilled tubesheets, or integrated flange-type tubesheets according to equipment design.

Tubesheet Flange Specifications

Additional Specifications:

• Hole Type: Tube holes, bolt holes, tie rod holes, vent holes, drain holes
• Tube Layout: Triangular pitch, square pitch, rotated square pitch, customized layout
• Processing: CNC drilling, deep hole drilling, reaming, grooving, facing
• Cladding Options: Stainless steel cladding, nickel alloy cladding, weld overlay
• Custom Service: Special OD, ID, thickness, tube hole diameter, pitch, groove, and sealing face available





Tubesheet Flange Materials & Grades

Tubesheet Flange Dimensions

Tubesheet Flange Dimension Drawing

Tubesheet flanges are usually manufactured according to customer drawings because tube hole layout, thickness, sealing face, groove design, and material selection depend on heat exchanger structure, working pressure, temperature, and medium.

Advantages of Tubesheet Flange

Accurate Tube Hole Drilling

CNC drilling and precision machining ensure accurate tube hole diameter, pitch, and layout.

Strong Structural Support

Thick forged or machined construction provides stable support for tube bundles and pressure vessel connections.

Reliable Sealing Performance

Precision sealing face machining helps reduce leakage risk in heat exchanger and pressure vessel systems.

Custom Tube Layout

Triangular pitch, square pitch, rotated square pitch, and special tube patterns can be produced according to drawings.

Cladding and Overlay Options

Stainless steel or nickel alloy cladding improves corrosion resistance while controlling material cost.

Suitable for Complex Equipment

Tubesheet flanges are suitable for heat exchangers, condensers, boilers, evaporators, and chemical process equipment.

Applications

Shell and Tube Heat Exchangers

Used to fix and support heat exchange tubes in shell-and-tube heat exchanger systems.

Condensers

Applied in power plants, chemical plants, and refrigeration systems for condensation equipment.

Boilers and Evaporators

Used in boiler equipment, evaporators, and thermal process systems.

Petrochemical Equipment

Suitable for reactors, coolers, process vessels, and pressure equipment in petrochemical plants.

Power Generation

Used in steam condensers, feedwater heaters, cooling systems, and auxiliary heat exchange equipment.

Chemical Processing

Stainless steel, duplex steel, and nickel alloy tubesheet flanges are suitable for corrosive media and demanding process conditions.

Why Choose Us

Comprehensive Fabricating Capabilities

We coordinated manufacturing, warm treatment, machining, testing, and bundling beneath one roof. You get steady quality control all through the whole generation process.

International Standards Compliance

Our products meet ASME, EN, DIN, JIS, and GOST standards. You can specify the exact requirements for your regional applications with confidence.

Extensive Estimate Run

From DN15 to DN4000, we cover essentially all mechanical necessities. Your ventures advantage from single-source obtainment convenience.

Quality Affirmation

Progressed testing offices guarantee each product meets details. You get certified items with total traceability documentation.

Global Trade Involvement

Our items serve markets over Europe and the Americas. You work with demonstrated providers who get it worldwide quality expectations.

Competitive Preferences

Prevalent quality, competitive estimating, secure bundling, and quick conveyance combine to back your extend timelines and budgets.

FAQ

Q: What is a Tubesheet Flange?

A: A tubesheet flange is a thick drilled flange or plate used to support and fix tubes in shell-and-tube heat exchangers, condensers, boilers, and pressure vessel systems.

Q: Is Tubesheet Flange a standard pipe flange?

A: No. It is usually a customized heat exchanger component manufactured according to equipment drawings and design requirements.

Q: Can the tube hole layout be customized?

A: Yes. Tube hole diameter, tube pitch, hole quantity, layout pattern, groove, sealing face, and thickness can be customized.

Q: Can you make clad tubesheet flanges?

A: Yes. Stainless steel cladding, nickel alloy cladding, and weld overlay options can be supplied according to project requirements.

Q: What information is needed for quotation?

A: Drawings, material grade, OD, thickness, tube hole diameter, tube pitch, hole quantity, sealing face, cladding requirement, and inspection standard are recommended.
